Overhead stirrer EUROSTAR 200 control P4

IKA-Werke GmbH & Co.KG

€0.00

Content: 1

Product number: 9816712

Product information "Overhead stirrer EUROSTAR 200 control P4"

Extremely powerful laboratory stirrer for highly viscous applications for quantities up to 100 l (H₂O). It is designed with a removable wireless controller and a digital TFT display. It automatically adjusts the speed through microprocessor controlled technology within the speed range of 0/4 to 530 rpm (two speed ranges). The stirrer comes equipped with a RS 232 and a USB interface to control and document all parameters. An integrated torque trend display is provided for the measurement of viscosity changes. Safety circuits installed ensures automatic cut-off in an anti-stall or overload conditions. Continuous comparison of shaft speed to desired speed is maintained and variations are adjusted automatically. This guarantees a constant speed even with changes in viscosities of the sample.

Multilingual TFT display
Detachable remote control
Programmable functions
Integrated temperature measurement
Interval operation
Timer function
Adjustable safety circuit
Locked function
Infinitely adjustable speed
Speed range I: 4 to 110 rpm
Speed range II:16 to 530 rpm
Overload protection
Short-term overload operation

Clamping range:	0.5 ... 10 mm
Depth:	231 mm
Dimensions (WxDxH):	91 x 231 x 379 mm
Display:	Digital
Height:	379 mm
IP code:	IP 40
Manufacturer Article Number:	0004090000
Max. Viscosity:	150000 mPa·s
Max. clamping width:	10 mm
Max. speed:	530 1/min
Max. stirring capacity:	100 l
Max. temperature:	350 °C
Max. torque:	660 Ncm
Max. voltage:	230 V
Min. clamping width:	0.5 mm
Min. speed:	4 1/min
Min. temperature:	-10 °C
Plug type:	EU
Power supply:	230 V, 50/60 Hz
Power supply frequency:	50/60 Hz
Rated capacity:	134 W
Speed:	4 ... 530 1/min
Temperature:	-10 ... 350 °C
Type:	EUROSTAR 200 control P4
Type of auxiliary energy:	Mains connection
Weight:	5.8 kg
Width:	91 mm
With connection ext. temperature sensor:	Yes
With timer:	Yes
