Circulation thermostat with Peltier technology LOOP
Lauda Dr.R.Wobser GmbH & Co.KG
€0.00
Content: 1
Product number: 7646599
Product information "Circulation thermostat with Peltier technology LOOP"
Compact, air-cooled circulation thermostat for external applications. The refrigerant-free cooling technology ensures quiet and low-vibration operation.
- Bright and high-contrast graphic OLED display
- Intuitive 3-button operation
- User-friendly menu navigation in five languages
- RS 232 interface
- Pump connections with quick couplings for simple change of applications
- Small size and low weight
- Safety class I/NFL for operation with non-flammable liquids (water, water/glycol)
| Cooling capacity at 20 °C: | 0,12 kW |
|---|---|
| Ext. depth: | 301 mm |
| Ext. height: | 266 mm |
| Ext. width: | 175 mm |
| External dimensions (WxDxH): | 175 x 301 x 266 mm |
| Heating capacity: | 0.2 kW |
| IP code: | IP 21 |
| Manufacturer Article Number: | L000027 |
| Max. delivery pressure: | 0.8 bar |
| Max. flow rate: | 2.6 l/min |
| Max. temperature: | 80 °C |
| Max. voltage: | 240 V |
| Max. volume bath: | 0.3 l |
| Min. temperature: | 4 °C |
| Min. voltage: | 100 V |
| Plug type: | CEE |
| Power supply: | 100 ... 240 V, 50/60 Hz |
| Power supply frequency: | 50/60 Hz |
| Programmable: | No |
| Temperature: | 4 ... 80 °C |
| Temperature stability: | ±0,1 K |
| Type: | L 100 |
| Type of auxiliary energy: | Mains connection |
| Type of display: | OLED |
| Volume bath: | 0.3 l |
| Weight: | 6.9 kg |
